Sennheiser ASA214 Combiner (EW)

35,00

Active 2×1:4 (expandable to 1×1:8) antenna splitter with DC power distribution, 8 BNC cables, 470–870 MHz bandwidth, low insertion loss, high IIP3, and rugged all-metal chassis—ideal for multi-channel wireless setups.

SKU: 4150 Category:
+ Info

Description

When you rent sennheiser asa214 combiner ibiza, you get the ASA 214 Active Antenna Splitter—a full-metal RF distribution amp that lets two antennas feed up to four true-diversity receivers each (expandable to eight receivers by daisy-chaining units). The ASA 214-UHF covers 470–870 MHz at ±0 dB, while the ASA 214-1G8 handles 1785–1800 MHz, all with IIP3 ≥ 20 dBm and reflection loss ≥ 10 dB Sennheiser.

Key Features & Specifications

  • Splitter/Combiner Configuration: 2×1:4 active splitter or 1×1:8 combining amp

  • Frequency Range: 470–870 MHz (ASA 214-UHF) or 1785–1800 MHz (ASA 214-1G8) at –3 dB

  • RF Performance: IIP3 ≥ 20 dBm (min), 23 dBm (typical); insertion loss 0 ± 1 dB per path

  • DC Power Distribution: Four 12 V/350 mA outputs per branch via BNC—no extra PSUs needed

  • Included Accessories: NT 1-1 power supply with EU/UK/US/AU adapters and eight 50 cm 50 Ω BNC cables

  • Construction: Robust all-metal housing for superior RF shielding and road-ready durability

Explore more RF solutions in our RF combiners & splitters category.

Applications & Use Cases

Whether you rent sennheiser asa214 combiner ibiza for corporate conferences, outdoor festivals, or broadcast studios, the ASA 214 simplifies multi-channel wireless setups:

  • Live Events & Touring: Consolidate antenna runs and reduce rack space.

  • Fixed Installations: Permanent in-house distribution for theatres and houses of worship.

  • Mobile Productions: Quick deploy with integrated power distribution and minimal cabling.

Pair it seamlessly with our wireless microphone rentals to complete your RF chain.

Installation & Operation

Set up is plug-and-play: connect two high-gain antennas to the ANT RF IN A/B BNC sockets, power via the NT 1-1 unit, then route RF OUT A1–A4 and B1–B4 to your receivers. The ASA 214’s high third-order intercept and low loss maintain signal integrity across all outputs. For technical context on such devices, see the Wikipedia article on power dividers and directional couplers.

Rental & Support

White Sound Ibiza ensures a hassle-free rental when you rent sennheiser asa214 combiner ibiza:

Delivery & Pickup: Flexible scheduling across Ibiza.

On-Site Setup: Our RF specialists configure frequencies and optimize antenna placement.

Book now to secure the Sennheiser ASA 214 Combiner for your next Ibiza production and guarantee rock-solid, interference-free RF distribution!
